Environmental test equipment

ASTM UV accelerated weathering test machine for Insulating glass testing

Temperature range:-35～+70℃
Temperature gradient:≤1.5K/M
Heating power ≤15kw
Blast:550W×6pcs
Product description:Blast 550W×6pcs
INQUIRY EMAIL

ASTM UV accelerated weathering test machine for Insulating glass testing

Application:

It is limited:Curing, drying and storage of flammable, explosive and volatile substances; curing, drying and storage of corrosive substances; prohibiting the burning of flammable, explosive and corrosive articles; testing of biological samples or Storage

Technical Parameter:

Item	Parameter
Inner size	2200mm2200mm2550mm(WDH)
External size	2400mm* 2400 mm 2830mm(WD*H) does not contain protrusions
Test frame size	can be placed: Samples of 12 pieces (355 ± 6) mm (505 ± 6) mm (W L) Samples of (1400±6) mm * (2300 ± 6) mm (W*L)
Temperature range	-35～+70℃
Temperature fluctuation range	≤±1℃
Temperature uniformity	≤±3℃
Temperature deviation	≤±2℃
Temperature gradient	≤1.5K/M
Heating rate	Room temperature 25 ° C rose to 60 ° C time ≤ 30min
Humidity range	The relative humidity in the humidification stage is greater than 90%
Furnace wall insulation performance	Library insulation board
Noise index	Noise-resistant circulating box operation noise ≤ 70 decibels
Load	36 pieces of glass
Heating power	≤15kw
Blast	550W×6pcs
Water tank heating power	9000W
Compressor power	7.5HP × 2 sets (Bizeur, Germany)
Control panel	LCD true color touch screen 6.3 inch
Heating type	Electric heating tube / heating wire (nickel chrome wire)
Heater	Electric heating stainless steel fin electric heating tube
Power	Three phase 380V±10% 50HZ±10%
Test environment	The ambient temperature is 5 to 35 ° C and the relative humidity is ≤ 85% RH.
Standard	ASTM E2188
